PURETEC MAINS WATER FILTRATION INSTALLATION
Puretec WU50 Installation Brisbane & Gold Coast
JR Gas & Water supplies and professionally installs the Puretec WU50 mains water filtration system across Brisbane, the Gold Coast and surrounding eligible South East Queensland service areas.
The WU50 is Puretec's compact single-housing entry-level mains-water filter. It combines carbon filtration with sediment reduction in one replaceable cartridge and can be installed on a suitable water line where its 23L/min published maximum flow matches the required demand.
Puretec specifies a nominal 5-micron system rating, ¾-inch / 19mm connections and its ML101-DP multipurpose carbon replacement cartridge.
Compared with Puretec's larger twin-stage WU systems, the WU50 is simpler and more compact. That makes it useful where the goal is basic mains-water chlorine, taste, odour and sediment treatment without the larger cartridge capacity or higher published flow of a twin-housing whole-house system.
Puretec WU50 quick answer:
the WU50 is a compact single-stage mains-water filtration kit using one
ML101-DP multipurpose carbon cartridge. Puretec publishes a nominal 5-micron
system rating, maximum flow of 23L/min, ¾-inch / 19mm connections and a
200–875kPa pressure range. It requires no power and is intended for chlorine,
taste, odour, chemical, dirt and sediment reduction where the required water
flow suits this smaller system.
Puretec WU50 at a Glance
Product
WU50
Compact single-housing mains-water filtration kit.
Best Suited To
MAINS WATER
Properties wanting straightforward carbon and sediment treatment.
Installation Area
SEQ
Brisbane, Gold Coast and surrounding eligible South East Queensland areas.
Key Flow Figure
23 L/MIN
Puretec's maximum published flow rate for the WU50.
Who Is the Puretec WU50 For?
Mains-Water Properties
Designed for mains-water filtration where chlorine, taste, odour and sediment reduction are the main treatment priorities.
Lower Flow Requirements
Better suited where the required simultaneous filtered-water demand fits within Puretec's published 23L/min maximum flow.
Simple Entry-Level Filtration
A useful option where a compact single-housing system is preferred over a larger twin-stage whole-house filter.
PRODUCT SUITABILITY
Is the Puretec WU50 Right for My Property?
A Good Choice If...
You use mains water, want straightforward carbon and sediment filtration and your expected filtered-water demand suits a 23L/min maximum published flow.
Consider Another System If...
You need higher whole-house flow, separate sediment and carbon stages, longer cartridge capacity, UV disinfection, water softening or reverse osmosis treatment.
JR Should Check First If...
The filter will serve several high-flow outlets, incoming pressure is high, existing pipework is substantially larger than 19mm or the proposed mounting location has limited service access.
How Does the Puretec WU50 Work?
Water enters the filter housing: the WU50 is connected into a suitable mains-water line so incoming water passes through the installed cartridge.
One cartridge performs multiple treatment functions: Puretec specifies the ML101-DP multipurpose carbon cartridge as the replacement cartridge for this system.
Carbon treatment improves mains water: Puretec describes the WU50 as reducing chlorine, chemicals, taste and odour while also reducing sediment.
Filtered water continues downstream: after passing through the cartridge, water returns to the connected downstream plumbing.
No electricity is required: filtration operates using normal water pressure with no electrical pump or UV lamp.
What Does the Puretec WU50 Reduce?
Chlorine
Puretec identifies chlorine reduction as one of the principal functions of the WU50 carbon filtration system.
Taste & Odour
The multipurpose carbon cartridge is designed to improve unwanted taste and odour in mains water.
Dirt & Sediment
Puretec also specifies dirt and sediment reduction as part of the WU50's general-purpose filtration role.
The WU50 is not a water softener, UV steriliser or reverse osmosis
system.
It should be selected for the treatment capability of its standard carbon
cartridge rather than being expected to perform specialist hardness,
microbiological or dissolved-solids treatment.
Single-Stage Filtration — What Does That Mean?
The WU50 uses one filter housing and one multipurpose cartridge rather than separate sediment and carbon housings.
This keeps the system compact and relatively simple to service, but it also means one cartridge handles the filtration workload that larger twin-stage systems divide between separate cartridges.
For homes with higher flow requirements, heavier sediment loading or a preference for separate filtration stages, one of Puretec's larger WU10 or WU20 systems may be a more suitable direction.
Key Puretec WU50 Features
Single 10-Inch Cartridge
Uses a compact single-housing configuration rather than twin large-diameter filter housings.
23L/min Maximum Flow
Puretec publishes a maximum flow rate of 23 litres per minute.
5-Micron Nominal Rating
Puretec publishes a nominal 5-micron system filtration rating.
¾-Inch Connection
Uses approximately 19mm inlet and outlet connections.
Multipurpose Carbon Cartridge
Puretec specifies the ML101-DP cartridge for ongoing system servicing.
No Power Required
The standard WU50 operates using water pressure only.
Puretec WU50 Specifications
| Specification | Puretec WU50 |
|---|---|
| Brand | Puretec |
| Model | WU50 |
| Product Type | Single-housing mains-water filtration kit |
| Filtration Configuration | Single stage |
| Replacement Cartridge | ML101-DP multipurpose carbon cartridge |
| Nominal Micron Rating | 5 micron |
| Maximum Published Flow | 23L/min |
| Minimum Published Pressure | 200kPa |
| Maximum Published Pressure | 875kPa |
| Pressure Limiting Requirement | Approved pressure-limiting device required where supply pressure exceeds 500kPa |
| Minimum Water Temperature | 0°C |
| Maximum Water Temperature | 52°C |
| Connection Size | ¾" / approximately 19mm |
| Electrical Supply | Not required |
| Manufacturer Warranty | 1 year parts and labour, cartridges excluded, subject to current Puretec terms |
Puretec publishes a system pressure range up to 875kPa while separately requiring an approved pressure-limiting device when incoming pressure exceeds 500kPa. The exact supplied product and current Puretec instructions remain the final installation reference.
INSTALLATION REQUIREMENTS
What Is Required to Install a Puretec WU50?
Suitable mains-water supply
Appropriate filtration point on the water line
Filtered-water demand suited to the 23L/min published maximum
Compatible existing pipework
Incoming pressure checked before installation
Pressure limiting where supply exceeds 500kPa
Suitable isolation arrangement
Secure mounting position
Clearance for housing removal
Future cartridge-service access
Suitable protection for the installation location
System flushing and leak testing
Water Pressure & Pressure Limiting
Puretec publishes a pressure range of 200–875kPa for the WU50 but separately requires an approved pressure-limiting device when incoming pressure exceeds 500kPa.
This means site pressure should be checked during installation rather than simply assuming that any mains-water pressure is suitable without additional control.
Pressure control also needs to be considered alongside the rest of the property's plumbing arrangement so the filter is protected while practical downstream flow is maintained.
Is 23L/min Enough for My Home?
The WU50's published 23L/min maximum flow is lower than Puretec's larger twin-housing WU systems.
Whether it is suitable depends on what plumbing the WU50 will serve and how much water is likely to be used at the same time.
A property where one or two moderate-flow outlets operate at once can have very different demand from a large home using multiple showers, baths, laundry and outdoor taps simultaneously.
Do not select the WU50 on price alone if it will be filtering the full
household supply.
The expected simultaneous flow needs to suit the system so filtration does not
become an unnecessary restriction.
Installation Position & Cartridge Access
The WU50 is more compact than Puretec's larger twin-stage whole-house systems, but it still needs an accessible installation position.
The filter bowl needs enough clearance for removal when the ML101-DP cartridge is replaced.
Isolation valves, fittings and the mounting point should also remain accessible after installation so cartridge servicing can be completed without unnecessary dismantling of surrounding equipment.
JR Puretec WU50 Installation Packages
JR's current live WU50 selector uses six installation pathways so the selected package can reflect whether the job is an exact replacement, wall mounted or freestanding and whether the incoming water main is already exposed.
Base — Exact Replacement
For exact replacement of an existing Puretec WU50 where the existing pipework, installation position and mounting arrangement remain suitable.
Silver — Wall Mounted, Exposed Main
For a new wall-mounted installation where the incoming water main to the dwelling is already exposed, including valves and pipework within current package scope.
Gold — Freestanding, Exposed Main
For a new freestanding installation where the incoming water main is exposed, including valves, pipework and concreted supports within current package conditions.
Sapphire — Wall Mounted, Main Not Exposed
For wall-mounted installations where the relevant incoming water pipework is not already exposed, including valves and pipework within current package scope.
Diamond — Freestanding, Main Not Exposed
For freestanding installations where the incoming water main is not exposed, including valves, pipework and concreted supports within current package allowances.
Platinum — Broader Powered Installation
JR's current Platinum pathway includes valves, pipework, a double power point and concreted supports where required. The standard WU50 itself does not require electrical power.
Use JR's live selector above as the final reference for current package inclusions, installation timing, allowances and pricing.
What Can a JR WU50 Installation Include?
Supply of the genuine Puretec WU50
ML101-DP replacement cartridge supplied with system as applicable
Professional system positioning
Connection to suitable mains pipework
Valves according to selected package
Pipework according to selected package
Wall mounting where selected
Freestanding supports where selected
Pressure assessment
System flushing
Leak and connection checks
Basic cartridge servicing guidance
Exact inclusions depend on the current JR package selected and actual site conditions.
What May Require Additional Work?
Pressure-control work beyond selected package scope
Major incoming-water-main relocation
Substantial pipe-size alterations
Structural wall or mounting work
Difficult concealed pipe access outside package allowances
Protective enclosure unless expressly included
UV disinfection equipment
Water softening or specialist scale treatment
Reverse osmosis treatment
Rectification of unrelated plumbing defects
Puretec WU50 Installation Pricing
Current supplied-and-installed pricing is controlled through JR's live product and installation selector above rather than being hardcoded into this description.
Final scope depends on whether the job is an exact replacement, wall mounted or freestanding, whether the incoming water main is exposed, pressure-control requirements and the amount of additional pipework needed.
JR's live selector also controls current Priority Saver and Express booking options, so the selector above should be used for current timing and availability.
BRISBANE INSTALLATION
Puretec WU50 Installation Brisbane
JR Gas & Water installs suitable Puretec WU50 filtration systems throughout Greater Brisbane for mains-water properties wanting a simple single-stage carbon filtration setup.
Brisbane installations are assessed around incoming water pressure, expected flow, pipe size, the location of the water main and future cartridge-service access.
A straightforward wall-mounted installation on exposed pipework can have a very different scope from a concealed-main installation or a property requiring a freestanding support arrangement.
JR also services Logan, Ipswich, Redlands, Moreton Bay and surrounding eligible South East Queensland areas, subject to current booking availability.
GOLD COAST INSTALLATION
Puretec WU50 Installation Gold Coast
JR Gas & Water provides suitable WU50 supply and installation across eligible Gold Coast service areas.
The compact single-housing format can suit properties wanting straightforward mains-water filtration where the required flow fits within the system's published 23L/min maximum.
Incoming pressure, existing pipework, mounting position and cartridge servicing access should all be confirmed before the installation is treated as straightforward.
Can the WU50 Replace My Existing Water Filter?
Replacing Another WU50
Usually the simplest pathway where the existing pipework, pressure, mounting position and isolation arrangement remain suitable.
Replacing Another Single Filter
Often possible, but connection size, housing clearance, cartridge type, pressure and intended flow should be checked before treating the job as like-for-like.
Replacing a Twin Whole-House System
Possible on some properties, but moving to a smaller single-stage system may reduce cartridge capacity and available flow, so treatment goals should be checked first.
Puretec WU50 vs WU10-25M
| Feature | WU50 | WU10-25M |
|---|---|---|
| Water Source | Mains water | Mains water |
| Filtration Stages | Single stage | Twin stage |
| Cartridge Format | Single 10-inch multipurpose carbon cartridge | Separate 10-inch sediment and carbon cartridges |
| Maximum Published Flow | 23L/min | 30L/min |
| Connection Size | ¾" / 19mm | 1" BSP / 25mm |
| General Fit | Compact entry-level filtration | Higher-flow twin-stage whole-house filtration |
The WU50 is the simpler and lower-flow option. The WU10-25M separates sediment and carbon filtration into two housings and provides a higher published maximum flow, making it more suitable where whole-house demand justifies the larger system.
WU50 vs Under-Sink Drinking-Water Filtration
WU50 Mains-Line Filtration
Designed to be connected into a mains-water line and provide general carbon and sediment treatment to downstream plumbing.
Under-Sink Drinking-Water Filter
Treats one dedicated kitchen outlet and can use a more specialised cartridge because it does not need to support broader household flow.
The right approach depends on whether the priority is broader household filtration or more specialised filtration at one drinking-water outlet.
Puretec WU50 Cartridge Maintenance
| Component | Current Puretec Reference | Function |
|---|---|---|
| Replacement Cartridge | ML101-DP | Multipurpose carbon filtration for the WU50 |
Cartridge life depends on water consumption, chlorine loading, sediment levels and local mains-water conditions.
Reduced flow, pressure drop or noticeable changes in filtered-water quality can indicate that cartridge replacement is required.
Puretec specifies genuine replacement cartridges for maintaining the intended WU50 filtration configuration.
COMMON QUESTIONS
Puretec WU50 Installation FAQs
What is the Puretec WU50?
It is a compact single-housing mains-water filtration kit using one multipurpose carbon cartridge.
Is the Puretec WU50 a whole-house filter?
It can be installed on a suitable mains-water supply to provide filtration to downstream outlets, but its 23L/min published maximum flow is lower than Puretec's larger twin-stage whole-house models. The actual household demand should therefore be checked first.
Is the WU50 suitable for mains water?
Yes. Puretec specifically markets the WU50 for mains-water filtration.
What does the WU50 reduce?
Puretec describes the system as reducing chlorine, harmful chemicals, taste, odour and sediment.
What cartridge does the WU50 use?
Puretec currently specifies the ML101-DP multipurpose carbon cartridge.
What is the nominal filtration rating?
Puretec publishes a nominal system rating of 5 micron.
What is the maximum flow rate?
Puretec publishes a maximum flow rate of 23 litres per minute.
What size connections does the WU50 use?
Puretec specifies ¾-inch connections, approximately 19mm.
Does the WU50 require electricity?
No. Puretec lists the WU50 as requiring no power.
What water pressure does the WU50 allow?
Puretec publishes a pressure range of 200–875kPa for the product.
Why is a pressure-limiting device required above 500kPa?
Puretec specifically states that an approved pressure-limiting device needs to be fitted where incoming pressure exceeds 500kPa, despite the broader published product pressure range.
What is the water temperature range?
Puretec currently publishes a 0–52°C water-temperature range.
Does the WU50 remove fluoride?
Puretec does not describe the standard WU50 cartridge as a dedicated fluoride-reduction system.
Does the WU50 disinfect water?
No. The standard WU50 does not include a UV disinfection stage.
Does the WU50 soften hard water?
No. It is not a conventional water softener and should not be selected as a dedicated hardness-removal system.
Is 23L/min enough for a full house?
It depends on simultaneous water demand. Smaller or lower-demand installations may suit the WU50, while homes regularly operating several high-flow fixtures together may benefit from a larger-flow system.
What is the difference between the WU50 and WU10-25M?
The WU50 is a single-stage system rated up to 23L/min with 19mm connections. The WU10-25M uses separate sediment and carbon stages, 25mm connections and has a higher published maximum flow of 30L/min.
Can the WU50 replace my existing water filter?
Often, yes. Connection size, available flow, pressure, mounting position and cartridge clearance should still be checked before treating the job as an exact replacement.
What is JR's Base WU50 package?
JR's current Base pathway is for exact replacement only of an existing Puretec WU50 where the existing installation remains suitable.
What is JR's Silver package?
Silver is JR's current wall-mounted new-installation pathway where the incoming water main is already exposed, including valves and pipework within package scope.
What is JR's Gold package?
Gold is JR's current freestanding pathway where the incoming water main is exposed, including valves, pipework and concreted supports within package scope.
What if my incoming water main is not exposed?
JR's current Sapphire and Diamond packages provide wall-mounted and freestanding pathways where the incoming pipework is not already exposed.
Why does JR list a Platinum package if the WU50 needs no power?
The standard WU50 itself requires no electricity. JR's Platinum package is a broader installation pathway for sites where electrical provision forms part of the overall installation setup.
What installation timeframes does JR currently offer?
JR's current live selector includes Priority Saver and Express installation choices. Use the live selector above for current availability and timing.
How much does Puretec WU50 installation cost?
Current supplied-and-installed pricing is shown through JR's live selector. Final scope depends on the selected package, pipework, pressure, mounting arrangement and site conditions.
Can JR install the WU50 in Brisbane?
Yes. JR installs suitable Puretec WU50 systems throughout eligible Greater Brisbane service areas.
Can JR install the WU50 on the Gold Coast?
Yes. JR provides suitable WU50 supply and installation across eligible Gold Coast service areas.
Does JR install the WU50 in Logan?
JR's current WU50 product information includes Logan within its stated installation coverage, subject to current booking availability and site conditions.
Puretec WU50 Warranty & Maintenance
1-Year Manufacturer Warranty
Puretec currently lists one year parts and labour for the WU50, subject to current manufacturer warranty terms.
Cartridge Is a Consumable
Puretec excludes replacement cartridges from the standard manufacturer warranty.
Service Access Matters
Future cartridge replacement is easier when isolation and housing clearance are considered during installation.
Puretec's manufacturer warranty is separate from JR's installation workmanship and support terms. Manufacturer coverage remains subject to current Puretec conditions and correct installation, use and maintenance.
Why Choose JR Gas & Water for WU50 Installation?
LICENSED
Plumbing installation completed through appropriately licensed professionals.
SYSTEM CHECK
Expected flow, incoming pressure, pipe sizing and installation position considered before the system is finalised.
COMMISSIONING
System flushing, connection checks and leak testing completed before handover.
SEQ
Brisbane, Gold Coast and surrounding eligible South East Queensland service coverage.
The WU50 is a compact filtration system, so matching it to the required water flow is particularly important. JR considers pressure, intended demand, pipework, mounting position and cartridge access before finalising the installation.
RELATED FILTRATION OPTIONS
Compare Whole-Home & Puretec Water Filters
Compare the WU50 with JR's wider whole-home mains filtration and Puretec ranges if your property needs more flow, twin-stage filtration, larger cartridges or a different water-treatment setup.
READY TO INSTALL
Install the Puretec WU50 With JR Gas & Water
The Puretec WU50 is a compact entry-level mains-water filtration option for suitable properties wanting chlorine, taste, odour and sediment treatment without moving to a larger twin-housing system.
Before installation, confirm incoming pressure, required water flow, pipe size, mounting arrangement, cartridge-service clearance and whether additional pressure control or pipework alterations are required.
Not only are we productreview.com.au 2023 national winner of the Best Plumbers category we were also voted national Best Home Care store which shows that our customers don't just love our great product prices but our product knowledge, customer service, attention to detail and second to none installation quality.
Being competitively priced is very important to us, we are not going to be the cheapest but like thousands of our customers 5-star reviews can attest to, for that little bit more you get a lot more, with great service, a superior installation, aftersales support, and what you generally miss out on with the cheapest install, manufacturer backed warranty. We guarantee our work won't leave you high and dry if you are the unlucky few that have a system die under warranty.
Â
More from JR Gas & Water
Recently viewed
