PURETEC WHOLE-HOUSE RAINWATER FILTRATION
Puretec EM2-150 Installation Brisbane & Gold Coast
JR Gas & Water supplies and installs the Puretec EM2-150 whole-house rainwater filter across eligible Brisbane, Gold Coast and surrounding South East Queensland service areas.
The current Puretec EM2-150-LF is a heavy-duty dual-stage point-of-entry filtration system designed primarily for rainwater supply. It is intended to filter water before it enters the home, office or building so connected taps, showers, laundries and appliances receive filtered water throughout the property.
The system uses a 20-micron washable pleated sediment cartridge followed by a 1-micron polyspun sediment cartridge. Puretec rates the EM2-150 at up to 150 litres per minute through a large 1½-inch BSP connection, making it one of the highest-flow sediment-focused models in the EM2 range.
Puretec EM2-150 at a glance: EM2-150-LF, dual 20-inch housings, PL20MP2 20-micron pleated sediment cartridge, PX01MP2 1-micron polyspun cartridge, 150 L/min maximum flow, 200–520kPa current operating-pressure range, 0–52°C temperature range, 1½" BSP / 40mm connections, gravity-feed capable, no power required, UV pre-filtration compatible and current 10-year Puretec warranty.
Puretec EM2-150 Supply & Installation at a Glance
150 L/min Maximum Flow
Puretec rates the EM2-150 at up to approximately 150 litres per minute.
Dual Sediment Filtration
The system combines 20-micron first-stage filtration with a finer 1-micron second stage.
1½" Main-Line Connections
The large 40mm connection size supports higher-flow whole-property plumbing layouts.
No Power Required
The EM2-150 is a passive filtration system with no pump, electronics or moving filtration components.
What Is the Puretec EM2-150?
The Puretec EM2-150 is a dual-stage whole-house filter designed to reduce sediment and particulate contamination from rainwater and other suitable water sources.
Unlike an under-sink drinking-water filter, the EM2-150 is installed on the main water line before water is distributed throughout the property.
This means the filtration applies to multiple connected outlets rather than only one drinking-water tap.
Puretec positions the EM2 series as high-flow whole-building filtration with minimal flow restriction, particularly where sediment, sludge, rust and algae need to be reduced before the water reaches household fixtures and appliances.
How Does the Puretec EM2-150 Filter Water?
Stage 1 – PL20MP2 20 Micron
The first stage uses the PL20MP2 pleated sediment cartridge. Puretec identifies this as the washable sediment stage used to capture larger dirt, rust, algae and suspended particulate material.
Stage 2 – PX01MP2 1 Micron
The second stage uses the PX01MP2 polyspun sediment cartridge to provide finer nominal 1-micron particulate filtration.
This staged arrangement allows the coarser cartridge to remove larger sediment before the water reaches the finer second-stage filter.
Why Choose the Puretec EM2-150?
High-Flow Whole-House Filtration
The 150 L/min rating is designed for larger residential or building applications where several outlets may operate at the same time.
Dual-Stage Sediment Reduction
The 20-micron and 1-micron stages progressively reduce suspended material rather than forcing one cartridge to perform all sediment treatment.
Heavy-Duty Housings
Puretec uses heavy-duty housings intended for whole-house protection and regular service access.
Integrated Aluminium Bracket
The system uses Puretec's integrated rust-resistant anti-flex aluminium wall-mount bracket.
Gravity-Feed Capable
Puretec states the EM2 series can operate on gravity-feed pressure where the hydraulic conditions are suitable.
UV Pre-Filtration
The EM2-150 can be used as pre-filtration ahead of a suitable ultraviolet treatment system.
PRODUCT SUITABILITY
Is the Puretec EM2-150 Right for Your Property?
A Good Choice If...
You have a larger rainwater-fed property and need high-flow whole-house sediment filtration before water enters the building.
Consider a Smaller EM2 If...
Your property has lower peak flow or smaller main pipework and does not require a 150 L/min, 1½-inch filtration system.
Consider UV Treatment If...
Your rainwater treatment goal includes microbiological disinfection. The EM2-150 itself is a sediment-filtration system, not a UV steriliser.
Suitable Water Sources
Puretec designs the EM2 series specifically for rainwater.
The current EM2-150 page also states that the system can be used with mains, river, dam and bore water where the water chemistry and treatment requirements are suitable.
That does not mean the EM2-150 alone makes every untreated source safe for drinking.
River, dam, bore and rainwater can require additional treatment depending on microbiological contamination, dissolved minerals, metals, hardness, pH and other water-quality conditions.
The EM2-150 should therefore be selected as part of the overall treatment strategy rather than treated as a universal purifier for every source.
Puretec EM2-150 Specifications
| Brand | Puretec |
|---|---|
| Current Model | EM2-150-LF |
| Product Type | Dual-stage whole-house / whole-building sediment filtration system |
| Primary Water Source | Rainwater |
| Other Listed Sources | Mains, river, dam and bore water where suitable |
| Housing Size | Dual 20-inch heavy-duty housings |
| Stage 1 Cartridge | PL20MP2 |
| Stage 1 Rating | 20 micron nominal |
| Stage 1 Type | Pleated washable sediment cartridge |
| Stage 2 Cartridge | PX01MP2 |
| Stage 2 Rating | 1 micron nominal |
| Stage 2 Type | Polyspun sediment cartridge |
| Maximum Flow Rate | 150 L/min |
| Minimum Pressure | 200kPa |
| Maximum Pressure | 520kPa |
| Minimum Temperature | 0°C, protect from freezing |
| Maximum Temperature | 52°C |
| Connection | 1½" BSP / 40mm |
| Gravity Feed | Supported where hydraulic conditions allow |
| Power Required | No |
| Moving Parts | No moving filtration components |
| Chemicals Required | No |
| UV Pre-Filtration | Suitable |
| Filter Cartridges Included | Yes |
| Current Warranty | 10 years |
| Warranty Structure | 1 year parts and labour + 9 additional years parts only |
Puretec's current EM2-150 product page specifies a maximum operating pressure of 520kPa. Older EM2 technical literature listed higher absolute pressure limits subject to pressure limiting above 500kPa, so the current product-page specification is used here.
150 L/min High-Flow Capacity
The EM2-150 is one of the highest-flow sediment-focused systems in Puretec's current EM2 whole-house range.
Its published maximum flow is approximately 150 L/min.
This makes it relevant to larger houses, acreages, offices and buildings where multiple fixtures may operate simultaneously and smaller filter connections could create unwanted restriction.
The actual flow available at the property still depends on the incoming water source, pump performance, pipe diameter, filter condition and pressure losses through the plumbing system.
1½-Inch Main-Line Connection
The EM2-150 uses 1½-inch BSP / 40mm connections.
This larger connection size distinguishes it from models such as the EM2-140, which uses a 1-inch connection.
The larger port size can help reduce unnecessary restriction in higher-flow plumbing layouts.
Installation should still be matched to the property's actual pipe size and hydraulic requirements rather than automatically reducing or enlarging pipework solely to match the filter ports.
No Power Required
The EM2-150 does not use an electrical controller, UV lamp or powered treatment process.
Water passes through the cartridges using the pressure already available from the property's pump, mains supply or suitable gravity-fed arrangement.
This makes the filtration stage mechanically simple and avoids electrical running costs for the filter itself.
Where UV disinfection is added downstream, the UV equipment will require electrical power even though the EM2-150 does not.
Suitable as UV Pre-Filtration
Puretec specifically identifies the EM2 series as suitable for UV system pre-filtration.
This is important because ultraviolet disinfection performs best when suspended sediment and turbidity are reduced before water reaches the UV chamber.
The EM2-150 can therefore form the sediment-filtration stage in a broader rainwater treatment system.
The EM2-150 itself does not kill bacteria or viruses. Where microbiological treatment is required, a suitable downstream disinfection system should be selected.
What Does the Puretec EM2-150 Reduce?
The EM2-150 is primarily a sediment filtration system.
Dirt
Rust
Algae and suspended material
Sediment
Sludge
Fine particulate material down to the nominal 1-micron second stage
The EM2-150 should not be marketed as a taste-and-odour carbon filter, water softener or microbiological steriliser.
Puretec's own EM2 range distinguishes the sediment-focused EM2-150 from models such as the EM2-100 and EM2-110 that use carbon treatment for taste, odour and chemical reduction.
Protecting Plumbing and Appliances
Whole-house sediment filtration can help reduce the amount of suspended material reaching taps, valves, ceramic-disc tapware and connected appliances.
Puretec specifically positions the EM2 series as helping protect appliances from sediment and sludge build-up and extending the service life of ceramic-disc tapware.
This does not eliminate every cause of appliance or plumbing wear, but it can reduce particulate loading through the building water system.
Puretec EM2-150 vs EM2-140
| Specification | EM2-150 | EM2-140 |
|---|---|---|
| Filtration | 20 + 1 micron sediment | 20 + 1 micron sediment |
| Housing Size | 20 inch | 20 inch |
| Maximum Flow | 150 L/min | 140 L/min |
| Connection | 1½" BSP | 1" BSP |
| Main Difference | Higher-flow 1½" plumbing format | Similar filtration with 1" connection |
The two systems use similar sediment-filtration stages. The key difference is the larger 1½-inch connection and slightly higher maximum-flow rating of the EM2-150.
Puretec EM2-150 vs EM2-110
| Specification | EM2-150 | EM2-110 |
|---|---|---|
| Maximum Flow | 150 L/min | 110 L/min |
| Connection | 1½" | 1½" |
| Filtration Type | 20 + 1 micron sediment | 5 micron sediment + carbon |
| Taste & Odour Treatment | No dedicated carbon stage | Yes |
| Main Positioning | Higher-flow sediment reduction | Sediment plus taste/odour treatment |
The EM2-150 is the stronger fit where high-flow sediment removal is the main goal, while the EM2-110 adds carbon treatment but at a lower maximum flow rate.
Cartridge Replacement and Maintenance
The EM2-150 uses genuine PL20MP2 and PX01MP2 replacement cartridges.
Puretec's maintenance guidance states cartridges should be inspected and replaced regularly, with typical replacement intervals commonly falling in the 6–12 month range depending on water quality and usage.
The first-stage pleated sediment cartridge is washable, which may allow cleaning during service where the cartridge remains in suitable condition.
The finer polyspun second-stage cartridge is a consumable replacement item.
Filter condition, pressure drop and actual water quality should determine servicing rather than relying only on a fixed calendar interval.
INSTALLATION REQUIREMENTS
What Is Required to Install the Puretec EM2-150?
Suitable incoming water source
Adequate wall or structural mounting location
Correct 1½" main-line pipework arrangement
Suitable isolation valves
Pressure within the current 200–520kPa operating range
Temperature within the 0–52°C operating range
Clearance beneath housings for cartridge servicing
Suitable bypass arrangement where required
Correct flow direction
Protection from freezing
Leak and pressure checks after installation
Access for future cartridge changes
Why Servicing Clearance Matters
The EM2-150 uses large 20-inch filter housings, so sufficient space needs to be left below and around the system for future cartridge replacement.
A technically functional installation can still become difficult and expensive to maintain if the bowls cannot be removed easily.
JR therefore considers service access, nearby walls, pumps, tanks, valves and other equipment when selecting the final mounting position.
The system should remain accessible without requiring unnecessary dismantling of surrounding plumbing every time the cartridges are serviced.
What's Included With Puretec EM2-150 Installation?
Genuine EM2-150 System
Supply of the current EM2-150-LF system with genuine PL20MP2 and PX01MP2 cartridges and factory wall-mount bracket.
Mounting & Commissioning
Mounting to a suitable structure, connection to suitable existing plumbing, leak checks, flushing and commissioning.
Possible Additional Work
Large-diameter pipe changes, bypass valves, isolation valves, pressure control, structural mounting work, relocation or pump-system alterations can increase installation scope.
How Much Does Puretec EM2-150 Installation Cost?
Current supplied-and-installed pricing is shown through JR's live product and installation selector where available.
The final Puretec EM2-150 installation cost depends on the incoming pipe size, water source, installation location, mounting structure, bypass arrangement, isolation valves, pressure conditions and the amount of pipework alteration required.
A straightforward installation into suitable existing 1½-inch plumbing is generally simpler than adapting a smaller existing line or rebuilding the pump and filtration layout.
BRISBANE INSTALLATION
Puretec EM2-150 Installation Brisbane
JR Gas & Water supplies and installs the Puretec EM2-150 in Brisbane for suitable rainwater, acreage and whole-property filtration applications.
The 150 L/min system can suit larger homes and buildings where high-flow sediment filtration is required before water enters the property.
JR checks water source, pump performance, main pipe size, available mounting space, pressure, servicing clearance and any planned UV treatment before confirming the final installation.
Eligible service coverage extends across Greater Brisbane and surrounding areas including Logan, Ipswich, Redlands and Moreton Bay.
GOLD COAST INSTALLATION
Puretec EM2-150 Installation Gold Coast
JR Gas & Water also supplies and installs the Puretec EM2-150 on the Gold Coast across eligible service areas.
For properties using rainwater throughout the home, the EM2-150 can provide high-flow sediment reduction before water reaches showers, taps, laundries and connected appliances.
JR assesses the water source, available pressure, pump duty, pipe size, mounting location and future servicing access before commissioning the filter system.
Can the Puretec EM2-150 Replace My Existing Whole-House Filter?
Replacing Another EM2-150
Usually the simplest pathway where the existing 1½-inch plumbing, bracket location and service clearance remain suitable.
Replacing a Smaller EM2
Possible, but the existing pipe size, pump flow and surrounding plumbing need to support the larger 150 L/min system.
Replacing a Single-Stage Filter
The dual-stage EM2-150 may provide finer sediment treatment but requires additional wall space and servicing clearance.
New Rainwater Filtration
A new setup needs to be designed around the tank, pump, property flow demand, main plumbing and any downstream UV system.
Adding UV Treatment
The EM2-150 can be used ahead of a suitable UV system where microbiological disinfection is part of the treatment goal.
Changing Water Source
Bore, river, dam or other water sources should be assessed for contaminants beyond sediment before assuming the EM2-150 alone is sufficient.
COMMON QUESTIONS
Puretec EM2-150 Installation FAQs
What is the current Puretec EM2-150 model?
Puretec currently identifies the system as EM2-150-LF.
Is the EM2-150 designed for rainwater?
Yes. Puretec specifically designs the EM2 series for rainwater whole-house filtration.
Can the EM2-150 be used on mains water?
Puretec states that it can also be used on mains water where suitable.
Can it be used on river, dam or bore water?
Puretec lists river, dam and bore water as possible applications, but those sources may require additional treatment depending on actual water quality.
What cartridges does the EM2-150 use?
The current system uses PL20MP2 in Stage 1 and PX01MP2 in Stage 2.
What micron ratings does the EM2-150 have?
The first stage is nominal 20 micron filtration and the second stage is nominal 1 micron.
Is the first cartridge washable?
Yes. Puretec describes the pleated first-stage sediment cartridge as washable.
Does the EM2-150 remove chlorine?
The EM2-150 is a sediment-focused 20-and-1-micron system and does not use the carbon cartridge configuration found in some other EM2 models. It should not be sold as a dedicated chlorine-removal system.
Does the EM2-150 kill bacteria?
No. The EM2-150 itself is not a UV or microbiological disinfection system. Puretec specifically identifies it as suitable pre-filtration for a separate UV system.
What is the maximum flow rate?
Puretec publishes approximately 150 L/min maximum flow.
What pipe size does the EM2-150 use?
The system uses 1½-inch BSP / 40mm connections.
What pressure does the EM2-150 operate at?
Puretec's current product page publishes an operating range of approximately 200 to 520kPa.
Why do older EM2 documents mention 875kPa?
An older Puretec EM2 technical sheet listed up to 875kPa and required pressure limiting above 500kPa. The current EM2-150 product page now publishes 200–520kPa, so the current specification is used for new installations.
What is the operating temperature range?
Puretec publishes approximately 0°C to 52°C, with protection from freezing required.
Does the EM2-150 require electricity?
No. The filter itself uses no electrical power.
Can the EM2-150 operate on gravity feed?
Yes. Puretec states that the EM2 series can operate on gravity-feed pressure where sufficient hydraulic conditions exist.
Can it be installed before a UV system?
Yes. Puretec specifically identifies the EM2 series as suitable for UV pre-filtration.
Are the cartridges included?
Yes. Puretec states that the required filter cartridges are included with the system.
How often should the filters be changed?
Puretec's maintenance material indicates cartridge servicing commonly falls within approximately 6–12 months, depending on water quality and usage. Actual pressure drop and cartridge condition should guide servicing.
What is the difference between EM2-150 and EM2-140?
Both use 20-and-1-micron sediment filtration. The EM2-150 has a 150 L/min rating and 1½-inch connection, while the EM2-140 is rated at 140 L/min with a 1-inch connection.
What warranty does the EM2-150 have?
Puretec currently lists a 10-year warranty: one year parts and labour plus nine additional years parts only, excluding cartridges and subject to warranty conditions.
How much does Puretec EM2-150 installation cost?
Final cost depends on the main pipe size, valves, bypass arrangement, mounting location, pressure conditions and amount of plumbing alteration required.
Can JR install the Puretec EM2-150 in Brisbane or the Gold Coast?
Yes. JR installs suitable whole-house filtration systems across eligible Brisbane, Gold Coast and surrounding South East Queensland service areas.
Puretec EM2-150 Warranty
10-Year Puretec Warranty
Puretec currently lists the EM2-150 with a 10-year system warranty.
Warranty Structure
The published structure is 1 year parts and labour plus 9 additional years parts only.
Cartridges Excluded
PL20MP2 and PX01MP2 cartridges are consumable filtration components and are excluded from the standard system warranty.
Puretec product warranty and JR installation workmanship warranty are separate. Use genuine Puretec replacement cartridges and retain the warranty documentation supplied with the actual system.
Claims Strengthened or Cleaned Up From the Existing EM2-150 Copy
Added exact EM2-150-LF model identification
Added dual 20-inch housing identification
Added PL20MP2 Stage 1 cartridge
Added PX01MP2 Stage 2 cartridge
Confirmed 20-micron + 1-micron sediment filtration
Confirmed 150 L/min maximum flow
Confirmed 1½" BSP / 40mm connections
Updated operating pressure to current 200–520kPa manufacturer specification
Confirmed 0–52°C operating temperature
Confirmed rainwater-first manufacturer positioning
Confirmed mains, river, dam and bore applications where suitable
Confirmed gravity-feed capability
Confirmed no-power operation
Confirmed washable first-stage cartridge
Confirmed suitability for UV pre-filtration
Confirmed filter cartridges are included
Clarified that EM2-150 is sediment filtration, not carbon taste-and-odour treatment
Clarified that EM2-150 does not itself disinfect rainwater
Removed generic claims that cheaper systems are inherently unreliable
Confirmed current 10-year Puretec warranty structure
Why Choose JR Gas & Water for Whole-House Filtration?
JR Gas & Water supplies and installs whole-house water filtration systems across Brisbane, the Gold Coast and eligible surrounding South East Queensland service areas.
The correct whole-house system depends on more than maximum flow. Water source, pump duty, pipe diameter, pressure, contaminant type, peak household demand, servicing access and whether UV or other treatment is required all influence the final design.
JR assesses the existing property and water source before confirming whether the EM2-150, another EM2 model or a broader filtration and disinfection system is the better fit.
READY TO INSTALL
Install the Puretec EM2-150 With JR Gas & Water
The Puretec EM2-150-LF combines high-flow 150 L/min whole-house filtration, 20-and-1-micron staged sediment treatment, heavy-duty 20-inch housings and large 1½-inch connections in a passive system requiring no electrical power.
Its strongest fit is larger rainwater-fed homes, acreages and buildings where sediment reduction and strong whole-property flow are priorities, particularly where the filtration system may also act as pre-treatment for downstream UV disinfection.
JR Gas & Water supplies and installs suitable Puretec EM2-150 systems across eligible Brisbane and Gold Coast service areas. Choose the applicable live installation package above, or use JR's quote pathway where the job involves large-diameter pipework, pressure control, bypass plumbing, structural mounting changes, pump alterations or integration with UV treatment.
